Electron transmission through non-tunneling regime of GaAs-AlGaAs Coupled Quantum Well
Mizanur Rahman, Sujaul Chowdhury* Nanostructure Physics Computational Lab., Department of Physics, Shahjalal University of Science and Technology, Sylhet 3114, Bangladesh.
We have investigated electron transmission through non-tunneling regime of a semiconductor nanostructure called Coupled Quantum Well (CQW). Oscillatory transmission coefficient as a function of energy is found to show spectacular waxing and waning in amplitude. Corresponding features are expected to be observed in optical (Physical Review B 54 (1996) 1541) and quantum transport (Physical Review Letters 58 (1987) 816) experiments and hence the results besides verifying the Physics will have impact on future devices based on CQW.
With development of molecular beam epitaxy, two-dimensional systems similar to Quantum Wells (QWs) have been intensely studied in the past two decades and the results are about confined states in QWs. In recent years, however, people have investigated unbound states 3-23 in a series of semiconductor heterostructures including QWs. G Bastard presented theoretical study of continuum states of QW of “separate confinement heterostructures”. G. Bastard et al. studied bound and virtual bound (resonant) levels of GaAs- AlGaAs CQWs and showed parametric variation of energy levels. G. Bastard presented results of calculations of bound and virtual bound states of QWs, “separate confinement heterostructures” and superlattices. M. Heiblum et al. reported theoretical and experimental study of electrons transmission through non-tunneling regime of QW structures and ventured to relate transmission coefficient with I-V characteristics. W. Trzeciakowski et al. presented a simple method of calculating global density of states in resonant tunneling structures. S. Fafard have studied transmission coefficient in non-tunneling regime of QWs. Jian-Ping Peng et al. have studied transmission coefficient in non-tunneling regime of double barrier structures; they presented analytical results of life-time for both quasi-bound and extended resonant states. W. Trzeciakowski et al. have studied change in density of states in above barrier states of symmetric and asymmetric QWs introduced by some localised potential. W. Trzeciakowski et al. have derived dispersion relations connecting transmission amplitude and change of density of states introduced by scattering potential. Marcello Colocci et al. have demonstrated existence of above-barrier states in double barrier QW structures. C. D. Lee et al have reported direct observations of numerous above barrier states in QW structures. W. Lu et al. have demonstrated existence of above- quantum-step quasi-bound states in QW heterostructures. R. Ferreira and G. Bastard have presented an excellent review of unbound states in quantum heterostructures.
Bandgap engineering provides possibility of controlling electronic and optical properties of semiconductor QW heterostructures by varying layer thickness and material compositions. Several non-conventional structures have been proposed and realized for both investigating peculiar aspects of carrier physics and improving performances of QW devices. Two quantities have been frequently used to characterize the properties: transmission coefficient and density of states. Now-a-days people are more interested about QW applications in next generation applications in nanoscale. C. S. Liu investigated exciton dynamics in CQW. Wei Wei et al. conducted a study on TMD QWs and the results indicate that QWs hold promise in wide range of applications. More recent work can be found in reference, .
S. Chowdhury and C. C. Sarker investigated electron transmission through non-tunneling regime of isolated QW and found oscillations in transmission coefficient versus energy curves monotonic in amplitude. S. Chowdhury and M. Hasan investigated electron transmission through non-tunneling regime of single rectangular tunnel barrier and also found oscillations in transmission coefficient versus energy curves monotonic in amplitude. P. Sutradhar and S. Chowdhury investigated
electron transmission through non-tunneling regime of symmetric rectangular double barrier and found spectacular waxing and waning in amplitude of oscillatory transmission coefficient versus energy curves. S. Chowdhury and A. Rahman obtained parametric variations of T = energy of transmission peaks of symmetric rectangular double barrier in non-tunneling regime and found to their surprise that one of the 3 parametric variations in non-tunneling regime is completely different from that in tunneling regime.
This paper presents a theoretical study of transmission of electron through non-tunneling regime of GaAs-AlGaAs CQW. The paper is organized as follows. In sec. II, we present analytical results on transmission coefficient of CQW. A discussion of the results is reported in sec. III and the concluding remarks are given in Sec. IV.
II. Transmission coefficient of Coupled Quantum Well for non-tunneling regime
Abbildung in dieser Leseprobe nicht enthalten
Using the potential energy profile of Fig 1, we have calculated transmission coefficient T(E) of Coupled Quuantum Well for E > V0 i.e. for nontunneling regime and obtained
Abbildung in dieser Leseprobe nicht enthalten
Here T1 is transmission coefficient of single Quantum Well.
III. Results and discussions
We have used the equations of section II in the form of programs written in Mathematica and have plotted T as function of E and investigated characteristic features of the T versus E curves. Typical T versus E curve is shown by undashed curves in Fig. 2(c) and (d); looking at these curves, we find striking amplitude modulated oscillatory behaviour of T versus E curve of Coupled Quantum Well for non-tunneling regime. Amplitude of the oscillations show spectacular waxing and waning as a function of energy E.
 Sujaul Chowdhury; "Quantum Mechanics” Narosa / Alpha Science (2014)
 Sujaul Chowdhury; "Nanostructure Physics and Microelectronics” Narosa / Alpha Science (2014)
 G. Bastard; Physical Review B 30 (1984) 3547.
 G. Bastard, U. O. Ziemelis, C. Delalande, M. Voos, A. C. Gossard, W. Wiegmann; Solid State Communications 49 (1984) 671.
 G. Bastard; Superlattices and Microstructures, 1 (1985) 265.
 M. Heiblum, M. V. Fischetti, W. P. Dumke, D. J. Frank, I. M. Anderson, C. M. Knoedler, L. Osterling; Physical Review Letters 58 (1987) 816
 W. Trzeciakowski, D. Sahu, Thomas F. George; Physical Review B 40 (1989) 6058.
 S. Fafard; Physical Review B 46 (1992) 4659
 Jian-Ping Peng, Yao-Ming Mu, and Xue-Chu Shen; Journal of Applied Physics 73 (1993) 989.
 W. Trzeciakowski and M. Gurioli; Journal of Physics: Condensed Matter 5 (1993) 105.
 W. Trzeciakowski, M. Gurioli; Journal of Physics: Condensed Matter 5 (1993) 1701. Marcello Colocci, Juan Martinez-Pastor, Massimo Gurioli; Physical Review B 48 (1993) 8089.
 C. D. Lee, J. S. Son, J. Y. Leem, S. K. Noh, Kyu-Seok Lee, C. Lee, I. S. Hwang, H. Y. Park; Physical Review B 54 (1996) 1541.
 W. Lu, Y. M. Mu, X. Q. Liu, X. S. Chen, M. F. Wan, G. L. Shi, Y. M. Qiao, S. C. Shen, Y. Fu and M. Willander; Physical Review B 57 (1998) 9787.
R. Ferreira and G. Bastard; Nanoscale Research Letters 1 (2006) 1:120-136.
 C. S. Liu, H. G. Luo and W. C. Wu, Physical Review B 80 (2009) 125317
 W. Wei, Y. Dai, C. Niu, B. Huang, Scientific reports 5, Nature 17578 (2015).
 J. Frigerio, V. Vakarin, P. Chaisakul, M. Ferretto, D. Chrastina, X. Le Roux, L. Vivien, G. Isella, D. Marris-Morini, Scientific Reports 5, Nature 17398 (2015).
 Ahmed Fadil, Daisuke lida, Yuntian Chen, Jun Ma, Yiyu Ou, Haiyan Ou, Scientific Reports 4, Nature 6392 (2014).
 S. Chowdhury and C. C. Sarker; Oscillatory transmission through non-tunneling regime of isolated Quantum Well, Grin Verlag (2013)
 S. Chowdhury and M. Hasan; Oscillatory transmission through non-tunneling regime of single rectangular tunnel barrier, Grin Verlag (2013)
 P. Sutradhar and S. Chowdhury; Oscillatory resonant transmission waxing and waning in amplitude, Lambert Academic Publishing (2012)
 S. Chowdhury and A. Rahman; Oscillatory Transmission Through Non-Tunneling Regime of Symmetric Rectangular Double Barrier, GRIN Verlag (2013)
