Flow Maldistribution in Tube Bundles. Application on Air-Cooled Steam Condensers

Title: Flow Maldistribution in Tube Bundles. Application on Air-Cooled Steam Condensers

Scientific Essay , 2018 , 44 Pages

Autor:in: Dipl.-Ing. Hans Georg Schrey (Author)

Engineering - Power Engineering
Excerpt & Details   Look inside the ebook
Summary Excerpt Details

Tube bundles are standard equipment in heat exchanger design. Typically, when passing the bundle the process flow is subject to several flow re-directions which in consequence, lead to an uneven process side flow profile in parallel tubes. This may be harmless if speed differences are on a low scale. If, however a certain level of maldistribution is exceeded the operator may be confronted with severe consequences.

Orifice design to ensure even flow rates in pre-heater applications are well-known in boiler design. Specific equations to assess maldistribution and to design orifices in different flow arrangements have been developed for that purpose.

Less attention so far, has been paid to the field of air-cooled steam condensers (“ACCs”) although, occasionally some plants encounter problems of steam side maldistribution. This is visible by excessive sub-cooling of border areas (“cold spot” formation) at some condenser bundles caused by premature termination of steam condensation. As a result, the plant performance is badly affected. Moreover, in cold climates these cold spots are a potential risk of frost formation which must be definitely prevented.

Well-known calculation procedures of maldistribution will be summarized in PART ONE of this report by creating a unified theory applicable to all types of flow arrangement (single-phase) based on matrix algebra. It is shown how this method can be successfully applied to geometry variations.

In PART TWO, the procedure is extended to flow maldistribution of condensing steam in a typical ACC street (two-phase). The basics physics are diligently explained. The procedure enables proper design of ducting geometry. Conclusions for safe everyday operation – especially at variation of ambient conditions - are drawn.

Excerpt


At a glance

  • Transfer-matrix model covers Z, U, L and T flow arrangements
  • Cold-spot criterion applied to a centrally positioned dephlegmator layout
  • Minimum-flow calculations examine dephlegmator design duties of 1/7 and 1/5
  • Matrix method models header changes using 10, 20 or more sub-exchangers
  • 23 figures and 3 tables

Contents

1 Introduction

2 Tube Bundle Model

3 Basic Flow Arrangements

3.1 ‘Z’ Flow

3.2 ‘U’ Flow

3.3 ‘L’ Flow

3.4 ‘T’ Flow

3.5 Arbitrary Flow Arrangements

4 Header Geometry and Orifice Variation

5 Steam Flow Variation in ACC Streets

6 Cold Spot in ACC Primary Condenser

6.1 Condensate Collection Line

6.2 Separate Bottom Header in Primary Condenser

7 Cold Spot in ACC Secondary Condenser

8 Steam Mass Flow Limit

9 Complete ACC Street Model

10 Summary

Objectives and Topics

This work develops a unified mathematical approach to flow maldistribution in parallel tube bundles and asks how it can be extended to condensing steam in air-cooled condensers. It uses the resulting model to examine flow arrangements, condenser geometry, operating conditions and the prevention of cold spots.

  • Mass and momentum balances for tube bundles
  • Transfer-matrix solutions for single-phase flow arrangements
  • Variable header geometry and tube orifices
  • Two-phase steam flow in air-cooled condenser streets
  • Cold-spot criteria and minimum steam flow
  • Primary and secondary condenser design and operation

Excerpt from the Book

5 Steam Flow Variation in ACC Streets

Thermal power plants need large re-cooling units at the cold end of the steam cycle to recover the turbine steam. Low investment was one of the main reasons to use wet cooling equipment for this purpose - however, at the cost of extreme cooling water consumption. Over the years with rising environmental awareness cooling technology has been changed to completely abstain from wasting water for cooling or condensation. Contemporary thermal power cycles are equipped with air-cooled steam condensers (“ACCs”) using dry ambient air as cooling medium even in large scale units.

Low exhaust steam pressures which are relevant for total plant efficiency can only be reached in ACCs with large diameter steam ducting. As the whole ACC system operates in vacuum accumulation of inert gas in parts of the ACC must be avoided under all circumstances. If at some location the full amount of steam is consumed the condensate may be sub-cooled before reaching the bottom header. A so-called “cold spot” evolves where inert gases become stationary ([1] – [7]) which enables sub-cooling. This situation must be prevented by all means.

Large ACCs consist of multiple streets of exchanger modules in form of an ‘A’ frame served by a common manifold (fig. 6). Steam enters the primary heat exchanger modules from the top and is partly condensed during flow down to the condensate collection line (“CCL”) from where the condensate is drained down to the tank. Turbine exhaust steam wetness is collected on the turbine duct internal surface and drained via an extra line to the tank. So, we may assume that steam entering the bundles is dry. After passing the primary modules the remaining (dry) steam flows to the secondary exchanger or dephlegmator inlet where the terminal condensation is done in reflux mode. At the secondary top exit the evacuation system removes all remaining inert gas from the steam cycle.

In the context of this investigation the total secondary duty will always be considered a known boundary condition. At this point we make some simplifying assumptions without losing generality.

Chapter Summaries

1 Introduction: The introduction outlines the problem of uneven tube-bundle flow and the motivation for extending established single-phase methods to condensing steam.

2 Tube Bundle Model: An idealized bundle model combines mass continuity and momentum balances in a differential matrix equation and derives a transfer-matrix solution.

3 Basic Flow Arrangements: Boundary conditions are developed for Z, U, L and T flow, followed by a discussion of arbitrary and reversed arrangements.

4 Header Geometry and Orifice Variation: The model is extended to stepwise changes in header and tube geometry through linked exchanger and boundary matrices.

5 Steam Flow Variation in ACC Streets: The analysis introduces condenser-street components and incorporates condensation, drainage and two-phase density into the calculation.

6 Cold Spot in ACC Primary Condenser: A primary-condenser cold-spot criterion is applied to combined and separate bottom-header designs, with attention to duty fractions and geometry.

7 Cold Spot in ACC Secondary Condenser: The secondary condenser is analyzed as a reverse-flow arrangement, including the effects of header design, splitting and nozzle flow.

8 Steam Mass Flow Limit: A minimum-flow criterion is developed for fixed condenser geometry and evaluated for different header and dephlegmator conditions.

9 Complete ACC Street Model: The final model connects primary module groups across secondary-condenser discontinuities using boundary conditions and matrix calculations.

10 Summary: The work brings together the matrix procedure and its application to condenser design and operation.

Keywords

flow maldistribution, tube bundles, air-cooled steam condensers, single-phase flow, two-phase flow, transfer matrix, mass flux, header geometry, steam duct design, cold spots, condensate collection line, dephlegmator, steam mass flow

Frequently Asked Questions

What is this work about?

It examines uneven flow in parallel tube bundles and applies a mathematical model to air-cooled steam condensers.

What are its central topics?

The main topics are flow arrangements, matrix-based calculations, header geometry, steam condensation and cold-spot prevention.

What is the primary objective?

The objective is to develop a unified calculation method for flow maldistribution and extend it to condensing steam in condenser streets.

What scientific method is used?

The author derives an analytical model from mass continuity and momentum balances, solves it using matrix calculus and evaluates representative design scenarios.

What does the main analysis cover?

It develops the tube-bundle model, examines standard flow arrangements and applies the method to primary and secondary condensers, minimum steam flow and complete condenser streets.

Which keywords characterize the work?

Key terms include flow maldistribution, transfer matrix, two-phase flow, air-cooled condenser, header geometry, cold spot and dephlegmator.

How are different flow arrangements treated?

The same matrix framework is adapted to Z, U, L and T arrangements by specifying their boundary conditions; reversed arrangements are also discussed.

Why does the dephlegmator matter?

Its heat-duty fraction enters the steam-flow and cold-spot calculations, while its position and subdivision affect the condenser-street layout considered in the examples.

How does the work account for changing header geometry?

It represents geometry changes as a sequence of exchanger sections connected by boundary matrices, allowing different header areas and tube-side resistances.
