The fast and the furious phosphor: Its action in innate immunity.

Friedrich Flachsbart

H. Minasyan discovered the antimicrobial action of erythrocytes.1

F. Flachsbart discussed with him the antimicrobial action of coagulation and the action of unfractionated heparin in infection, especially sepsis.2

But the question remains:

Is there something like a deeper common ground of innate immunity?

Prof. Goebel showed in microbes that the metabolism is connected with invasive behaviour and that mammalian metabolism is connected with defence of microbial invasion.3

Is metabolism also the common ground of different lines of defence against invasion?

Let us try to find an answer by looking back to the beginning of life on earth.

When life on earth began, it was a combination of phosphor, sugar and nitrogen.

These elements build up the RNA world. This term was first used 1986 by Gilbert.4

Phosphor, the sugar ribose and a nucleobase combine to RNA.

RNA is the most important ingredient of life, especially in the “constant battle between infectious agents trying to subvert host defence systems and host cells protecting themselves from infection”.5 It started with RNA. And it still runs with RNA.

The question is:

How are these first ingredients of life still integrated in the communication between different species of microbial and eukaryotic species?

A first answer is:

They are still the first line of interaction between microbe and man.

Let us start with phosphor.

Phosphor provides energy. Phosphorylation activates other molecules.

Phosphor acts as information transmitter. Phosphorylation opens channels that provide information to other molecules, even cascades and nets of molecules. The enzymes of phosphorylation are called kinases. Phosphatases stop their action. Kinases and phosphatases form a highly integrated network of information flow. Edwin H. Fischer and Edwin G. Krebs showed us this fascinating world of phosphorylation.6

Phosphor is also the backbone of ribonucleic acid, RNA, the older nucleic acid.

RNA is very active in transformation and translation of the genetic DNA-information.

RNA is also part of many regulations and actions of cells.

There are important differences between the four RNA-molecules. But all four are part of the innate immunity, at different places and structures. Let us find the differences between the four ribonucleotides.

All four ribonucleotides attach phosphor and bind it in the four RNA-Triphosphates:

Adenosine-Tri-Phosphate (ATP).

Guanosine-Tri-Phosphate (GTP).

Uridine-Tri-Phosphate (UTP).

Cytidine-Tri-Phosphate (CTP).

1. ATP and GTP store energy.

ATP, Adenosine-Tri-Phosphate, is the most important energy transporter.

ATP and its derivatives NADPH, FADH store energy and transmit energy.

GTP, Guanosine-Tri-Phosphate is also an energy transporter.

GTP receives energy mostly from the citric-acid-cycle.

2. ATP and GTP transmit information.

ATP also serves as signal molecule.

The binding of phosphate by enzymes, called kinases, is the starter of enzyme action. Phosphor is a regulatory molecule, Phosphorylation induces the action of many enzymes.

Phosphatases stop this action. Kinases and Phosphatases are combined in a fine tuned network.

Phosphorylation by kinases means „go“, dephosphorylation by phosphatases means „stop“.

3. GTP acts with GPCR: Transmembrane information flow.

GTP is the substrate of G-PCR, G-Protein-Coupled-Receptors. Seven-helical-transmembrane-receptors are inactive with GTP. Dephosphorylation of GTP to GDP changes the protein-conformation and the information from outside the membrane is transformed into the action of number of signal-molecules inside the cell. These GPCR are involved in many information-pathways. Most pharmacological substances act via GPCR. But the most important function may be the interaction with microbes.7

4. Signalling with cyclic Monophosphates. Second messengers.

Adenyl cyclase forms cyclo-AMP (c-AMP), Guanyl cyclase build cyclo-GMP (c-GMP). These are important signal-molecules.8 They are triggered by small molecules, hormones, neurotransmitters like adrenalin, serotonin. Together with Calcium 2+, 1,2-Diacylglycerol (DG) and Inositol-1,4,5-Triphosphat (IP3) they activate the Protein-Kinase and Protein-Phosphatase-Networks. In fungi cAMP induces pathogenic structures.9 In Mycobacterium tuberculosis cAMP is upregulated in the state of infection.10 cAMP is active in the pathogen and host, cAMP can be a helper or a killer, friend or foe.11 cAMP protects bacteria against viral infections,12 cAMP protects man against virus.13 It was found, that heparin interacts with cAMP.14

5. UTP is the coenzyme for activation of sugar.

The phosphorylation of sugar allows the building of polymers like glycogen. The Glucose-1-Phosphate-UTP-Transferase changes UTP and glucose-1-phosphat into an UDP-hexose and pyrophosphate. UDP-glucose builds glycogen, the sugar-store. Connections between UTP, glycogen and microbes begin to emerge.15

6. CTP is part of membrane-building.

CTP and phosphocholine transforms into CDP-choline and pyrophosphate. CDP-diacylglycerol (DG) and phosphatidylinositol are the signal molecules together with Ca2+, cAMP and cGMP, as written above. Phosphatidylcholine is the outer membrane molecule, 50 % of the membrane are phosphatidylcholine. Base-exchange from phosphatidyl-choline and serine build up choline and phosphatidylserine, 10 % of the phospholipid of man. Phosphatidylserine is most important in the inside-out flippase of membranes.16 Phosphatidylserine seems to be a central focus of sepsis induced organ dysfunction.17

7. Phosphate and haemoglobin. (2,3-DPG)

A stereochemical change of haemoglobin is triggered by a small molecule, 2,3-Diphosphoglycerat (2,3-DPG) changes the oxygen-transport-capacity of haemoglobin. Without 2,3-DPG haemoglobin has only 8 % oxygen-transport-capacity. 2,3-DPG could also be a defence against reactive oxygen species (ROS) and reactive nitrogen species (NOS).18

8. Phosphate, Glucose and haemoglobin. (Favism)

The stereochemical change of glucose is induced by phosphor. Phosphorylation of glucose to glucose-6-phosphat is the starting point of glycolysis.19 Glucose is not able to leave the cell. In erythrocytes energy is provided only by glucose. The mutation of the enzyme glucose-6-phosphate-dehydrogenase20 induces a haemolytic anaemia.21 This disease, called favism since Hippocrates, is a survival benefit against malaria (like thalassaemia and sickle-cell-anaemia). Sickle cell anaemia is a major cause of thrombosis.22

9. Phosphate and Diabetes.

2002 the idea was presented: Silent occult streptococci are the common soil of diabetes and vascular disease.23 The kinase-cascades of IKKbeta induce an inflammation in rheumatic fever and in insulin-resistance. Aspirin (7g/day) stops the activation of the kinases.24 The effect of aspirin was 1877 first documented by Wilhelm Ebstein, who later became director of the internal medicine clinic of the university Goettingen. 1901 his observation was again documented by Williamson.25 1957 rheumatic fever and diabetes were together treated with one drug, aspirin.26

10. Phosphate and Gout/Pseudogout.

The end product of ribonucleic-acid (nitrogenous base-pentose-phosphate) is uric acid, inducing gout.27 Pseudogout is the association of phosphate with calcium.28 Gout and pseudogout are inflammatory states. They are antimicrobial inflammations, uric acid and calcium-phosphate kill the microbes. Prof. Wilhelm Ebstein, Göttingen, wondered more than 100 years ago, why there was not one microbe found in gout, when there were millions of streptococci visible in erysipelas in his patients.29

11. Phosphate, Xanthin and Asthma.

Adenosin and ATP interact with allergens to induce asthma. The receptors are part of a purinergic signalling system.30 Heparin is a therapeutic antagonist of severe chemical induced bronchial destruction.31

12. PolyP, the polyanion unfractionated heparin and RNA, DNA, histones and NET act in thrombosis.

Polyphosphates (PolyP) are stored in dense granules within thrombocytes. PolyP triggers coagulation Factor XII (Hagemann-Factor).32 Bradykinin is part of an inflammatory/thrombotic pathway.33

Polyphosphates (PolyP) and unfractionated heparin are stored in granules within mast cells.34 It is suggested, „that the release of heparin coupled with polyP inhibits the procoagulant properties of polyP while retaining the proinflammatory capability.35

Polyphosphates and unfractionated heparin are polyanions.36 They do not fit into the concept of „key and lock“: They activate other molecules not only by a specific key that does fit into a specific hole.37 PolyP and UFH activate other molecules by diffuse interactions of many atoms of the molecules.

Extracellular RNA is another polyanion that interferes with coagulation like PolyP.38 Both induce thrombosis. Unfractionated Heparin is the antagonist, inducing bleeding.

DNA, histones and NET, neutrophil extracellular traps, also interact with coagulation. All three are in complex ways intertwined with coagulation, induce thrombosis.39 Unfractionated heparin is the antagonist, inducing bleeding.

UFH binds to heparin-binding-proteins (HBP) in an unspecific manner. And there are hundreds of proven UFH-Protein-combinations.40 LMWH, interacting with a specific pentasaccharide of a thrombosis-factor seems to be not inferior in prevention of venous thrombosis. But UFH does so much more, it interacts with membranes, proteins, cells. In the USA only UFH is allowed in heart-surgery and dialysis.

UFH interacts with thrombosis. UFH interacts earlier in the road to infection, in the attachment of a pathogen. Ebola is an example. UFH stops the entrance of the virus. LMWH, interacting with thrombosis, does not interact with the virus-entry.41

This is the answer to the question: “Why is the sepsis mortality so high?”42

Sepsis mortality became so high, because UFH was lost in the treatment of sepsis. Only in extreme thrombotic states UFH is allowed.43

Unfractionated heparin interacts with invading pathogens in various protein-combinations. UFH dissolves attachment of pathogens to eukaryotic cells. Prof. Kuhn started his therapy of septic abortion in 1964 with 30.000 IU/day UFH one hour before antibiotic treatment. And so he could prevent intravascular thrombosis of kidney and lung, disseminated intravascular coagulation and bleeding.44 UFH does have many different contact-phases, not one as LMWH and not two, as Levi wrote.45 Sepsis and thrombocytopenia can be changed by the polyanion UFH, not by LMWH.46


1 H. Minasyan: Phagocytosis and oxycytosis: two arms of human innate immunity. Immunol Res 2018;66(2):271-280

2 H. Minasyan, F. Flachsbart: Blood coagulation: a powerful mechanism in human innate immunity. Int Rev Immunol 2019;38(1):3-17

3 W. Eisenreich, J. Heesemann, T. Rudel, W. Goebel: Metabolic host responses to infection by intracellular bacterial pathogens. Frontiers in Cellular and Infection Microbiology 2013;3:24 doi:10.3389/fcimb.2013.00024

4 W. Gilbert: Origin of life: The RNA world. Nature 1986;319:618

5 T. R. Cech: The RNA Worlds in Context. Cold Spring Harb Perspect Biol 2012;4(7): a006742. Doi: 10.1101/cshperspect.a006742

6 P. Cohen: The origins of protein phosphorylation. Nature Cell Biology 2002;4:E127-E130

7 H. Cheng, C. M. Lear-Rooney, L. Johansen, E. Varhegyi, Z. W. Chen, G. G. Olinger, L. Rong: Inhibition of Ebola and Marburg Virus Entry by G Protein-Coupled Receptor Antagonists. J Virol 2015;89(19)9932-8. Doi: 10.1128/JVI.01337-15

8 C. Hoffmann, M. R. Leitz, S. Oberdorf-Maass, M. J. Lohse, K. N. Klotz: Comparative pharmacology of human beta-adrenergic receptor subtypes – characterisation of stably transfected receptors in CHO cell. Naunyn Schmiedebergs Arch Pharmacol 2004;369(2):151-9

9 Y.- H. Lee, R. A. Dean: cAMP Regulates Infection Structure Formation in Plant Pathogenic Fungus Magnaporthe grisea. The Plant Cell 1993;5:693-700

10 G. Bai, D. D. Schaak, K. A. McDonough: cAMP levels in Mycobacterium tuberculosis and Mycobacterium bovis BCG increase upon infection of macrophages. FEMS Immunol Med Microbiol 2009;55:68-73. Doi:10.1111/j.1574-695X.2008.00500.x

11 M. E. Moreno-Fernandez, C. M. Rueda, P. A. Velilla, M. T. Rugeles, C. A. Chougnet: cAMP During HIV Infection: Friend or Foe? AIDS Res Hum Retroviruses 2012;28(1):49-53. Doi: 10.1089/aid.2011.0265

12 D. Cohen, S. Melamed, A. Millman, G. Shulman, Y. Oppenheimer-Shaanan, A. Kacen, S. Doron, G. Amitai, R. Sorek: Cyclic GMP-AMP signalling protects bacteria against viral infections. Nature Sept 18. Doi: 10.1038/s41586-019-1605-5 (Epub ahead of print)

13 K. Majzoub, F. Wrensch, T. F. Baumert: The Innate Antiviral Response in Animals: An Evolutionary Perspective from Flagellates to Humans. Viruses 2019;11(8). Pii:E758. Doi: 103390/v11080758

14 H. T. Zeng, Z. Ren, L. Guzman, X. Wang, M. L. Sutton-McDowall, L. J. Ritter, M. De Vos, J. Smitz, J. G. Thompson, R. B. Gilchrist: Heparin and cAMP modulators interact during pre-in-vitro maturation to affect mouse and human oocyte meiosis and developmental competence. Hum Reprod 2013;28(6):1536-45. Doi: 10.1093/humrep/det086

15 M- D- Asención Diez, A. M. Demone, K. Syson, D. G. Arias, A. Gorelik, S. A. Guerrero, S. Bornemann, A. A. Iglesias: Allosteric regulation of the portioning of glucose-1-phosphate between glycogen and trehalose biosynthesis in Mycobacterium tuberculosis. Biochim Biophy Acta 2015;1850(1):13-21. Doi: 10.1016/j.bbagen.2014.09.023

16 R. Panatala, H. Hennrich, J. C. M. Holthuis: Inner workings and biological impact of phospholipid flippases. Journal of Cell Science 2015;128:2021-2032. Doi: 10.1242/jcs.102715

17 G. Beattie, C. Cohan, E. Miraflor, W. Brigode, G. P. Victorino: Protective effect of phosphatidylserine blockade in sepsis induced organ dysfunction. Surgery 2019; doi: 10.1016/j. surg. 2019.05.020. (Epub ahead of print)

18 E. Tellone, D. Barreca, A. Russo, A. Galtieri, S. Ficarra: New role for an old molecule: The 2,3-diphosphoglycerate case. Biochim Biophys Acta Gen Subj 2019;1863(10):1602-1607. Doi: 10.1016/j.bbagen.2019.07.002

19 S. Baskaran, P. J. Roach, A. A. DePaoli-Roach, T. D. Hurley: Structural basis for glucose-6-phosphate activation of glycogen synthase. Proc Natl Acad Sci U S A 2010;107(41):17563-17568. Doi: 10.1073/pnas.1006340107

20 H. C. Yang, Y. H. Wu, W. C. Yen, H. Y. Liu, T. L. Hwang, A. Stern, D. T. Chiu: The Redox Role of G6PD in Cell Growth, Cell Death, and Cancer. Cells 2019;8(9). Pii: E1055. Doi: 10.3390/cells8091055

21 L. Luzzatto, C. Nannelli, R. Notaro: Glucose-6-Phosphate Dehydrogenase Deficiency. Hematol Oncol Clin North Am. 2016;30(2):373-93. Doi: 10.1016/j.hoc.2015.11.006

22 J. L. Kwiatkowski, J. Kanter, H. J. Fullerton, J. H. Voeks, E. Denbenham, L. Brown, R. J. Adams, Post-STOP Study Group. Am J Hematol 2019 Sep 6. Doi: 10.1002/ajh.25635. (Epub ahead of print)

23 F. Flachsbart: Silent occult streptococci are the common soil of diabetes and vascular disease. Lecture at the advisory board of the XV Lancefield Symposium on Streptococci and Streptococcal Diseases, Braunschweig June 2002.

24 R. S. Hundal, K. F. Petersen, A. B. Mayerson, P. S. Randhawa, S. Inzucchi, S. E. Shoelson, G. I. Shulman: Mechanism by which high-dose aspirin improves glucose metabolism in type 2 diabetes. J Clin Invest 2002;109(10):1321-1326. Doi: 10.1172/JCI14955

25 R. T. Williamson: On the treatment of glycosuria and diabetes mellitus with Sodium Salicylate. Br Med J 1901:1(21j00)760-762. Doi: 10.1136/bmj.1.2100.760

26 J. Reid, A. I. MacDougall, M. M. Andrews: Aspirin and Diabetes Mellitus. Br Med J 1957;2(5053):1071-1074. Doi: 10.1136/bmj.2.5053.1071

27 T. Neogi: Gout. N Engl J Med 2011;364:443-452

28 A. K. Rosenthal, L. M. Ryan: Calcium Pyrophosphate Deposition Disease. N Engl J Med 2016;374:2575-2584

29 W. Ebstein: Die Natur und Behandlung der Gicht. Bergmann, Wiesbaden, 1906

30 K. A. Jacobson, D. K. Tosh, S. Jain, Z.-G. Gao: Historical and Current Adenosine Receptor Agonists in Preclinical and Clinical Development. Front Cell Neurosci 2019;13:124. Doi: 10.3389/fncel.2019.00124

31 P. R. Houin, L. A. Veress, R. C. Rancourt, T. B. Hendry-Hofer, J. E. Loader, J. S. Rious, R. B. Garlick, C. W. White: Intratracheal Heparin improves Plastic Bronchitis Due to Sulfur Mustard Analog. Pediatr Pulmonol 2015;50(2):118-126. Doi: 10.1002/ppul.23043

32 R. K. W. Mailer, L. Hänel, M. Allende, T. Renné: Polyphosphate as a Target of Interference With Inflammation and Thrombosis. Front Med Lausanne. 2019;6:76. Doi: 10.3389/fmed.2019.00076

33 J. H. Morrissey, S. H. Choi, S. A. Smith: Polyphosphate: an ancient molecule that links platelets, coagulation, and inflammation. Blood. 2012;119(25):5972-5979

34 D. Moreno-Sanchez, L. Hernandez-Ruiz, F. A. Ruiz, R. Docampo: Polyphosphate Is a Novel Pro-inflammatory Regulator of Mast Cells and is located in Acidocalcisomes. J Biol Chem 2012:287(34)28435-2844. Doi: 10.1075/jbc.M112.385823

35 V. Esteban, C. Pastor-Vargas (eds.): New Insights in Anaphylaxis. Lausann, Frontiers in Media, doi:10.3389/978-2-88945-467-9

36 P. Semenyuk, V. Muronetz: Protein Interaction with Charged Macromolecules: From Model Polymers to Unfolded Proteins and Post-Translational Modifications. Int J Mol Sci 2019;20(5):1252. Doi: 10.3390/ijms20051252

37 D. Petrovic, V. A. Risso, S. C. L. Kamerlin, J. M. Sanchez-Ruiz: Conformational dynamics and enzyme evolution. J R Soc Interface 2018;15(144):20180330. Doi: 10.1098/rsif.2018.0330

38 C. Kannemeier, A. Shibamiya, F. Nakazawa, H. Trusheim, C. Ruppert, P. Markart, Y. Song, E. Tzima, E. Kennerknecht, M. Niepmann, M.-L. von Bruehl, D. Sedding, S. Massberg, A. Günther, B. Engelmann, K. T. Preissner: Extracellular RNA constitutes a natural procoagulant cofactor in blood coagulation. PNAS 2007;104(15):6388-6393.

39 D. F. Noubouossie, M. F. Whelihan, E. Sparkenbaugh, R. Pawlinski, D. M. Monroe, N. S. Key: In vitro activation of coagulation by human neutrophil DNA and histone proteins but not neutrophil extracellular traps. Blood 2017;129(8):1021-1029. Doi: 10.1182/blood-2016-06-722298

40 M. C. Z. Meneghetti, A. J. Hughes, T. R. Rudd, H. B. Nader, A. K. Powell, E. A. Yates, M. A. Lima: Heparan sulfate and heparin interactions with proteins. J. R. Soc. Interface 2015;12:20150589

41 A. O’Hearn, M. Wang, H. Cheng, C. M. Lear-Rooney, K. Koning, E. Rumschlag-Booms, E. Varhegyi, G. Olinger, L. Rong: Role of EXT1 and Glycosaminoglycans in the Early Stage of Filovirus Entry. J Virol 2015;89(10):5441-9. Doi: 10.1128/JVI.03689-14

42 C. Fleischmann, D. O. Thomas-Rueddel, M. Hartmann, C. S. Hartog, T. Welte, S. Heublein, U. Dennler, K. Reinhart: Hospital incidence and mortality rates of sepsis – an analysis of hospital episode (DRG) statistics in Germany from 2007 to 2013. Dtsch Arztebl Int 2016;113:159-66. DOI: 10.3238/aerztbl.2016.0159

43 M. Levi, M. Scully: How I treat disseminated intravascular coagulation. Blood 2018;131:845-854. Doi:

44 W. Kuhn, H. Graeff: Infected abortion and disseminated intravascular coagulation (DIC). Heparin prevention and early diagnosis of the DIC. Med Welt 1971;22(29):1199-200

45 M. Levi: The dual face of heparin in severe infection. Blood 2014;123: 947-948. Doi:

46 A. Assinger, W. C. Schrottmaier, M. Salzmann, J. Rayes: Platelets in Sepsis: An Update on Experimental Models and Clinical Data. Front Immunol 2019;10:1687. Doi: 10.3389/fimmu.2019.01687
