Magnetic Fields in Galaxy Clusters

Bachelor Thesis, 2005

37 Pages, Grade: 1,0


Page 3

1 Introduction

Recently, magnetic fields in galaxy clusters have come to the attention of the scientific world as the largest-scale magnetic structures measured to the present date. While little is known about the origin of these fields and their evolution throughout cosmic time, the presence of large-scale magnetic fields may have important implications for the processes observed in galaxy clusters. Examples of these implications include inhibition of transport processes - such as heat conduction, spatial mixing of the gas, and the propagation of cosmic rays - or even dynamical importance through the Lorentz force and the additional magnetic pressure term. It is therefore of great scientific importance to determine the origin, evolution and structure of cluster magnetic fields and their relevance in structure formation and in astrophysical phenomena observed today in galaxy clusters.

1.1 Galaxy Clusters: Formation and General Properties

Clusters of galaxies are the largest gravitationally bound systems in the Universe. They can be recognized in the optical range as groups of galaxies which are located closer together than the average distribution. However, galaxies represent only around 5% of the total mass of a typical cluster. Most of the baryonic mass, roughly 20% of the total mass of the cluster, is contained in the form of hot ionized gas in the intracluster medium (ICM). The ICM is characterized by high temperatures (in the order of 10 8 K) and electron number densities in the range of 10 −3 cm −3 ; thermal bremsstrahlung emission from the hot gas in the intracluster medium is very intense in the X-ray spectrum, typical luminosities ranging between 10 43 10 46 erg/s. By far the largest contribution to the mass of galaxy clusters is the dark matter, which constitutes between 70-80% of the total mass and plays an important role in the development of the clusters. According to the model of hierarchical structure formation, clusters of galaxies are thought to form upon the gravitational merger of smaller units, such as groups and subclusters.

1.2 Theories Regarding the Origin of Cluster Magnetic


Our Universe is permeated by magnetic fields on different length scales and strengths. The most palpable example is our own planet, which has a magnetic field of about 0.5 G at its surface. Moreover, the magnetic activity of our Sun also affects life on Earth. Magnetic fields in the Sun are about 10 G at the poles and can reach up to 2000 G in sunspots. Magnetic fields have been measured in the intraplanetary medium (≃ 50µG), in protostars and neutron stars, in the intragalactic medium (≃ 5µG in the Milky Way). It comes as no surprise

Page 5

1.3 Measuring Cluster Magnetic Fields: Methods and Results

Apart from the questions posed towards the origin of the cluster magnetic fields, another important scientific research area regards their currently observable properties. There are three different methods which can be employed in order to determine the strengths of magnetic fields in the ICM.

1.3.1 Synchrotron radiation

The first of these methods makes use of synchrotron radiation luminosities. Synchrotron radiation is produced by relativistic electrons gyrating in a magnetic field due to the Lorentz force. The synchrotron emission spectrum shows a peak at a critical frequency which is proportional to the average magnetic field and the square of the Lorentz factor, γ, while the power emitted in synchrotron radiation depends linearly on the square of the average magnetic field and on γ 2 . The energy of the relativistic electrons can be shown to be proportional to the synchrotron luminosity and to the −3/2 th power of the magnetic field. The strength of the magnetic field is usually estimated by minimizing the total energy, namely the sum of the energy in relativistic particles and the magnetic energy. This condition is fulfilled when the two different energy contributions are roughly equal, which enables the calculation of the average magnetic field. Furthermore, the degree of polarization of the synchrotron radiation gives a measure of the field uniformity (linear polarization corresponding to a uniform magnetic field). From the synchrotron emission method, typical magnetic field strengths in the ICM are computed as 0.4 1 µG [3].

1.3.2 Inverse Compton effect

Another method employed to measure the average magnetic field strength in clusters uses Inverse Compton (IC) radiation luminosities in addition to synchrotron emission. The inverse Compton effect consists in the scattering of microwave background photons by the relativistic electron population. As a result, the microwave background photons gain momentum from the electrons and are turned into X-ray or gamma photons. Given that the IC and synchrotron radiations both originate from the same relativistic electron population, one arrives at a proportionality relation: Lsync u B , where both the

L IC u ph

IC and synchrotron radiations can be measured and u ph is the density of the CMB photon field which can be calculated, therefore one can solve for u B , the energy density of the magnetic field. Results of the IC method give average magnetic fields of 0.2 1 µG[3].

1.3.3 Faraday rotation maps

The Faraday rotation effect completes the set of methods currently used to measure cluster magnetic fields. The principle of this effect consists in the

Page 7

1.3.4 Reconciling magnetic fields derived from the three methods

Compared to synchrotron and IC measurements, Faraday rotation map analyses give magnetic fields which are roughly one order of magnitude larger. Several arguments can be invoked in order to explain this discrepancy. Firstly, the cluster magnetic field may show a range of coherence scales, and the presence of highly correlated small-scale fluctuations can enhance the rotation measures and thus produce higher estimates of the average field strength. Secondly, an anisotropic pitch-angle distribution would weaken the synchrotron radiation relative to the IC emission, leading to an underestimation of the IC-derived fields. Also, if a large relativistic population is located in the weak-field regions, a large part of the IC emission will come from low magnetic field-strength parts of the cluster.

1.3.5 The RM debate

The scientific debate regarding the calculation of magnetic fields from rotation maps has become increasingly intense as new methods of analyzing RM maps are being developed. As discussed by Rudnick [2], the evidence up to date is insufficient to prove the fact that the rotation measures are due to the ICM and not to a thin thermal skin mixed with the relativistic plasma of the emitting radio source. Moreover, Rudnick cites polarization percentages of 0.9±0.7 and 0.9 ± 1.0 in beams which were used to produce rotation maps, an uncertainty which is too large for the results to still be considered relevant. Analyzing the rotation map of the Coma cluster by removing sources embedded in the cluster and keeping only the rotation measures of background sources, Rudnick found that this cluster showed, within error limits, a zero averaged absolute value of the rotation measure, even close to the cluster center. Counterarguments in favor of cluster magnetic field-generated rotation maps are presented in a study by Clarke et. al. [1] who performed a statistical survey of rotation measures as a function of the impact parameter of the emitting source with respect to the cluster center. A clear broadening of the RM distribuion toward small impact parameters (below roughly 1 Mpc) was found, justifying the conclusion that rotation maps are due to the ICM rather than being intrinsic to the emitting source.

1.3.6 Improved methods to determine the magnetic fields from rotation maps

Recently, Enßlin and Vogt ([5], [6]) developed a method of analysing Faraday rotation maps which enabled them to use the RM of Hydra A to calculate the magnetic field of 7 ± 2µG at the cluster center, within the assumptions made about the most likely geometry of the field.

In the first stage, Vogt and Enßlin [6] assume an isotropically distributed

Page 10

than the beamsize (distance between two adjacent measurements in the RM map). Combining these two effects, the reliable part of the computed spectrum encompasses roughly one order of magnitude in k-space.

image a4e93e491e327ce7287533f281e4e779

Figure 3: Magnetic energy spectra computed by Vogt and Ensslin from observational data. The Fourier transformed beam sizes are represented by thick vertical lines. The other straight lines correspond to the increase in the energy density for the largest k

In the second stage of developing the method described above, Vogt and Enßlin [5] describe a maximum likelihood analysis of Faraday rotation measures which enables them to conclude a Kolmogorov-like power spectrum of the magnetic energy over at least one order of magnitude in k-space.

1.4 Simulations of Galaxy Clusters Involving Magnetic Fields

Several numerical simulations have been employed in order to model the evolution of magnetic fields with cosmic time and probe the theories postulating different origins of the fields, as well as determine the mechanisms by which the fields are amplified to the present value. In 1997, Kulsrud et. al. [7] employed the Biermann battery model in a hydrodynamic simulation including the magnetic fields passively (that is, neglecting dynamical importance of the magnetic fields for the gas) and found that in the protogalactic era the fields can be amplified from 0 to 10 −21 G. Following the phase where the Biermann battery appears as an important gener-ator of fields, the simulation by Kulsrud et. al. suggests further amplification of the fields by isotropic Kolmogorov turbulence associated with gravitational structure formation. However, due to the low resolution, the small turbulent scales could not be resolved therefore the computations were done using a simplified analytical model. Results of analytical calculation suggest a significant

Page 12

strongly amplified than what would be expected from simple compression (in which case we expect B ρ 2/3 ), which constitutes the effect of shear flows. In the same study, correlation lengths of the magnetic field were computed using an autocorrelation function similar to that described in [6]. Typical values were found between 46.1 and 62.6 kpc, roughly one order of magnitude larger than those discusses by Enßlin and Vogt [6] from observation data. The power spectra computed for the magnetic field followed a linear profile from which the power spectrum was determined between -2.3 and -3.1, much lower than expected from Kolmogorov turbulence (-5/3). The artificial rotation maps however seemed to correlate very well with current observations. One other important fact noted by Dolag is the large influence of cluster mergers which contribute significantly to increasing the cluster magnetic fields. The approximation of smoothed particle hydrodynamics is however believed not to be well-suited for resolving shocks and therefore cannot accurately describe cluster mergers. The purpose of the current study is thus to use an adaptive mesh-refinement (AMR) simulation, whose performance in terms of resolving shocks and cluster mergers is improved, and to compare the results with those from observational data and previous numerical models.

2 Theoretical Considerations

As described by the Friedman-Robertson-Walker metric, the universe is ex-panding, and the rate of expansion is variable in time. In cosmology the concept of ”comoving coordinates” has been introduced in order to account for this expansion. The real (spatial) coordinates are related to the comoving coordinates by

(14) r = a (t) x

The time-derivative of x is called ”peculiar velocity” and is not due to cosmic expansion but to the interaction between individual astrophysical objects. The Hubble constant is defined from observations as v/r = H where v is the receding speed of a galaxy at distance r from the Earth. Taking the derivative of 14 and neglecting peculiar velocities with respect to cosmic expansion rates we find v = d r/dt = a ˙ x + ˙ a x ˙ a x, thus the Hubble parameter in dependence of time reads.

image 883e0cf3526d462c410a734c1822a709

2.1 Friedman equation

The Friedman equation is the first of six equations which we will employ in order to solve for the cosmic evolution of the galaxy cluster. It relates the

Page 13

time-dependent Hubble parameter to density distributions in the universe:

image eb81320f365b0cd01f80383407e7e039

where Ω m , Ω r , Ω Λ , and Ω c are the present-day densities, respectively, of matter, radiation, cosmological constant and curvature divided by the critical total density which would result in a flat Universe.

2.2 Comoving coordinate transformation

The other five equations needed are the Poisson equation and the four MHD equations (continuity equation, momentum conservation, energy conservation and magnetic field evolution). In order to use the above named equations, we must first transform them to comoving coordinates. For this, we define comoving quantities in terms of the real quantities scaled by a conveniently chosen power of the scale factor a. A summary of scaled comoving quantities as a function of the real-space quantities (denoted with the upper index ∗) is given in 18 below.

ρ ρε image 287df2f4f16a6182ec067af1629a7a97

Here, ρ represents the gas density, v the velocity, p the pressure, B the

magnetic field vector, and ε the internal energy defined as


Excerpt out of 37 pages
